GC Section workings

A compilation of the services which worked through Woodford Halse in Big Four and BR days.

New additions placed here temporarily.

Click for full size image in a pop-up window. Use 'X' to close

This 1930s view from the road bridge comes from the topic about modelling the GC milk van and shows the "Banbury Motor" awaiting departure from the platform face that was recently put back into service. Woodford's C13 No 6063 has the train comprising an ex-GCR milk van and ex-GCR 50' carriages with an ex-London Suburban 50ft 3rd, a similar style brake end, and a clerestory, one of which would have been a composite. Photo: author's collection.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

A more recent view from 1951 looking the other way shows arrival of the "Banbury Motor" at the same platform behind J11 No 64369 (WFD) and what appears to be a school party spilling out. Photo: John Batts. There will eventually be a big chapter about this service through GCR, LNER and BR days.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

This view from the late 1930s is not as sharp as it could be because it has been copied, from what may have been a Dufaycolor slide judging by the diagonal texture. The scene is Banbury General (GWR) with the roof of Merton Street (LMS) station visible on the left, next to which lay Banbury's cattle market, at one time the largest in Europe. The station is as reshaped by the GWR with the platforms used for the "Banbury Motor" from Woodford Halse. Standing in the North Bay is Woodford Halse's Ex-GCR B5 "fish engine" 4-6-0 No 6071 with a 5-coach GWR excursion which comprises Collett panelled stock and a recently refurbished Dean clerestory.

In the foreground is the triangular goods plaftform, against which an autocoach, used for services to Hook Norton and to Princes Risborough, has been parked. An empty cattle truck awaits loading. Many more cattle trucks are in the sidings in the distance, the nearest being empties: GWR, LMS, LNER, SR (ex-LSWR), GWR, GWR, SR, SR, LMS. The manually braked trucks were common user so the mixture of types was quite normal.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

An interesting view at Banbury's NW bay platform with two ex-GCR "Atlantics". The date is not known but it's clearly a 1930s view on a Thursday, which was a double market day - in the town centre and the cattle market near the station. It's early evening and the summer sun is streaming down.

Nearest the camera is ex-GCR C4 No 6094 which was at Woodford from 1931 to 1937. The crew is relaxing on the platform with the loco carrying No 2 Braked or Express Goods lights, ready to take the Thursdays Only 6.25pm cattle express to the abattoirs in Sheffield.

Another feature of the market day workings is a C4 in the background with a barely visible "Banbury Motor" formation headed by a permanently-attached D.120-series brake van. This too was a market day only train laid on specially for the early evening (there wasn't normally a train back to Woodford and the halts along the way until later in the evening). It had left Woodford at 6.12pm and was scheduled to set off back at 7.3pm. Barely half an hour was allowed for the loco to run round its carriages and present them to passengers who would have come in earlier for a day's shopping "in town". Extra trains on a market day used to be common all over the country.

To the right, GWR horse boxes wait to be loaded in the Down goods bay in case of horse sale in the town centre market (rather than the cattle market). They would have been attached to a passenger train. Photo: F.A. Blencowe.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

GC Section locos used to go to Banbury Loco to use the turntable before setting off back to Woodford Halse and this is ex-GCR B7 4-6-0 No 5472 in 1935. The captions claims a date of 3rd August 1935 and a location of "Banbury shed". The date may be accurate but not the location - there is nothing recognisable as Banbury and I suspect that the actual location may have been Annesley, on whose books this B7 was from 1933-43. Photo: F.A. Wycherley.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

The date is Tuesday 2nd February 1953 and A3 No 60054 Prince of Wales (LEI) stands by no.1 platform, in BR green livery. It's probably about to leave with a Bournemouth-Newcastle express. Photo: F.A. Blencowe.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

B1 No 61192 of Woodford Halse swings into the Up main platform in August 1956 with the Sunday York-Swansea. Photo: Real Photographs.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

A nice picture but alas printed on textured paper so please don't look too closely! The "Banbury Motor" awaits departure from the north bay on a summer evening in 1959 or 1961 when this was one of Leicester's B1s, evidently borrowed by Woodford for the occasion. Ex-LMS carriages have replaced the ex-LNER ones and a non-gangwayed one without toilets is leading. Photo: GCRS.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

Taken into the light, sloping badly and quite a mucky print too, an hour's fixing has made it at least worth closer scrutiny for this is the station on Tuesday 23rd August 1955, the year before complete rebuilding began. In the distance stand the compact station buildings, awnings and covered footbridge.

On the far right is the station pilot, a "Hall" with lamps over each buffer. In full view is ex-LNER Thompson L1 2-6-4T No 67789 (WFD) waiting with a train over the Banbury Branch to Woodford Halse. The two train carriages are gangwayed 61'6" teak Gresleys in b&c livery - composite brake and third (BCK,TK). Two spare carriages are parked further back, an interesting mixture of a gangwayed 52'6" Gresley 3rd (still in varnished teak livery) and a Thompson non-gangwayed 52'4" composite brake (in BR crimson) - [TK,BC]. Photo: F.A.Blencowe.

Click on the image for an enlargement

Click for full size image in a pop-up window. Use 'X' to close

Seen on Saturday 11th June 1960, Leicester GC's V2 No 60890 pauses with the York-Bournemouth.

The photographer's notes on the print say much about how hard things were in 1960: "Pan F (a fine grain film) 1/100 f4 - Contax". With a modern camera on a sunny day you'd expect to have a higher f-stop and a better DOF than half the leading coach! Much of the train is a blur and impossible to identify.

Click on the image for an enlargement

Awfully blurry, I'm afraid, but Set No "88" can be seen and the leading three carriages:

  BSK

BR Mk.1

    CK

BR Mk.1

    SK

BR Mk.1

... rem unclear......

These coaches were probably in BR(S) green. The next two coaches are too blurry to be sure but may not have been BR Mk.1s. As far as I can gather from Mike King, Mark Hambly and the SR Email Group (Coach sets):

The set was probably 880 which was nominally a 4-set but by 1960 made up to 9 vehicles for inter-regional work and the Bournemouth-Newcastle (these formations changed a lot during the 1950s and early 1960s). The closest I can find was:

BSK, CK, SK, SO, RB, SO, SO, CK, BSK

Catering up to 1959 has been provided by an RKB, revised by 1961 with an RB. Note the provision of SOs either side of the buffet car; one third of the train made up with this type; and the few 1st Class seats near the outer ends. A pity that only a fraction of the formation can be seen on the picture, but an education all the same.

Click for full size image in a pop-up window. Use 'X' to close

Another view of the "Banbury Motor", in spring 1961 with Midlandisation in full swing as the train pulls away from the NE bay, visible in the distance, past Banbury North signal box. Ex-LMS Fairburn 2-6-4T No 42157 (WFD) is in charge of two ex-LMS coaches, thankfully both gangwayed with lavatories. Photo: D. Battersby.

Click on the image for an enlargement

To be continued...

Banbury station pictures are here.

Banbury yards and freight pictures are here.

Banbury express passenger pictures are here.

Banbury loco shed pictures are here.

Banbury light engines are here.

Banbury signal box pictures are here.

Ardley-Greaves Siding limestone traffic pictures are here.

Banbury Merton Street station is here.
